Brass Inserts
We specialize in manufacturing high-quality brass inserts, including molding inserts, male/female inserts, and threaded inserts, tailored to customer requirements and specifications. Our inserts are available with ISO metric (MM threads), BA threads, BSW threads, and UNC & UNF threads. We offer various plating options, such as natural, nickel-plated, tin-plated, or any custom coating per client specifications. Made from premium materials, including free-cutting brass (IS 319 Type I and BS 249 Type I), high-grade free-cutting brass, or special brass compositions as required, we also produce inserts using MS, SS, or copper materials based on provided drawings and specifications.
📊 Technical Specifications
| Parameter | Specification |
|---|---|
| Insert Types | Heat-set, Ultrasonic, Press-fit, Moulded-in, Knurled |
| Thread Range | M2 to M20 | 4-40 to 3/8"-16 UNC |
| Material | Free-cutting Brass (CZ121), Copper alloys |
| Outer Knurl | Diamond, Straight, or Helical knurl |
| Compatible Plastics | ABS, Nylon, Polycarbonate, POM, PP, PVC |
| Plating | Plain Brass, Nickel, Tin plated |
| Standards | DIN 16903, custom to drawing |
| Quality | ISO 9001:2015 Certified |
| MOQ | Flexible — small to large batches |
🔩 Need Custom Specifications?
Share your drawing, sample, or specification and get a free quote within 24 hours. No commitment required.
